Description
Specifications
Ports and performance
- Total ports: 26
- PoE+ ports: 24 x 10/100/1000Base-T ports (IEEE 802.3at/af)
- Uplink ports: 2 x 1000Base-X SFP ports
- PoE budget: 370W
- Switching capacity: 52 Gbps
- Forwarding rate: 38.69 Mpps
- Packet buffer: 4.1 Mbit
- MAC address table: 8K
- Maximum VLANs: 16
- Jumbo frame: 9K
Management and features
- Cloud management: Lifetime management through the Ruijie Cloud platform, accessible via a web interface or a mobile app.
- Zero-touch provisioning: Supports easy plug-and-play deployment.
- IP camera recognition: Automatically detects and optimizes network settings for IP cameras, making it ideal for CCTV networks.
- Remote functions: Allows for remote monitoring, configuration, rebooting of individual PoE ports, and fast fault diagnosis.
- Network reliability: Features include automatic loop prevention, flow control, port isolation, and broadcast storm suppression.
- PoE features: Offers adaptive power distribution to save energy and extend the transmission distance up to 250 meters.
Physical specifications
- Dimensions (W x D x H): 440 mm x 289 mm x 43.6 mm
- Weight (with package): 4.2 kg
- Installation: Rack-mountable (19-inch)
- Power supply: Built-in AC power (100–240V)
- Maximum power consumption: ≤ 443W
- Fan: Built-in, with speed control that can stop the fan at low temperatures.
- Port surge protection: 4 kV
Operating conditions
- Operating temperature: 0°C to 40°C
- Operating humidity: 10% to 90% RH (non-condensing)
- Storage temperature: -40°C to 70°C
- Storage humidity: 5% to 95% RH (non-condensing)
