Description
Key specifications
Performance
- Total Ports: 9 x 10/100/1000 Mbps Base-T ports.
- PoE Ports: 8 ports support IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) standards.
- PoE Budget: A total PoE budget of 120W, with a maximum of 30W per PoE port.
- Switching Capacity: 18 Gbps.
- Forwarding Rate: 13.39 Mpps.
- MAC Address Table: Supports up to 4K MAC address entries.
- VLAN: Supports up to 16 VLANs and port-based VLAN.
Features and management
- Cloud Management: Can be managed remotely via the Ruijie Cloud platform and mobile app, offering web-based and cloud management options.
- CCTV Optimization: Includes intelligent features like IP camera recognition and offline alarm.
- Loop Prevention: Automatic loop prevention ensures network stability.
- Extended PoE: Features an extend mode for PoE transmission up to 250 meters.
- Surge Protection: Provides 4 kV port surge protection.
- Other features: Supports flow control, port isolation, port mirroring, and broadcast storm suppression.
Physical and environmental
- Form Factor: Desktop, with a durable steel case.
- Dimensions (W x D x H): 202 mm x 108 mm x 28 mm.
- Weight (with package): 1.3 kg.
- Power Supply: External AC/DC adapter (54V DC, 2.4A).
- Maximum Power Consumption: 130W.
- Heat Dissipation: Fanless design for silent operation.
- Operating Temperature: 0°C to 40°C.
